Magnetic Transducer (AC)
| Part No. | Diameter Φ (mm) | Height (mm) | Operating Voltage (VAC) | Rated Voltage (VAC) | Max Rated Current (mA) | Coil Resistance (Ω) | Min Sound Output (dBA) | Resonant Frequency (Hz) | Operating Tempature (°C) | Terminal | Housing | Weight (g) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| CMT2512F1000NP | 25 | 12.5 | 3 ~ 8 | 6 | 70 | 36 ± 5 | 85 @ 10cm | 1000 | -40 ~ +85 | Pin | Noryl | 10 |
Please contact us for the datasheet of this product.
