Magnetic Transducer (AC)
| Part No. | Diameter Φ (mm) | Height (mm) | Operating Voltage (VAC) | Rated Voltage (VAC) | Max Rated Current (mA) | Coil Resistance (Ω) | Min Sound Output (dBA) | Resonant Frequency (Hz) | Operating Tempature (°C) | Terminal | Housing | Weight (g) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| CMT1612H2048NP | 16 | 12 | 6 ~ 18 | 12 | 50 | 135 ± 20 | 85 @ 10cm | 2048 | -40 ~ +90 | Pin | Noryl | 2 |
Please contact us for the datasheet of this product.
