Magnetic Transducer (AC)
| Part No. | Diameter Φ (mm) | Height (mm) | Operating Voltage (VAC) | Rated Voltage (VAC) | Max Rated Current (mA) | Coil Resistance (Ω) | Min Sound Output (dBA) | Resonant Frequency (Hz) | Operating Tempature (°C) | Terminal | Housing | Weight (g) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| CMT1210A2200TP | 12 | 10 | 0.8 ~ 2.5 | 1.5 | 100 | 3.5 ± 1 | 85 @ 10cm | 2200 | -20 ~ +70 | Pin | PBT | 2 |
Please contact us for the datasheet of this product.
