Self Drive Piezo Transducer (DC)
| Part No. | Diameter Φ (mm) | Height (mm) | Operating Voltage (VDC) | Rated Voltage (VDC) | Max Rated Current (mA) | Min Sound Output (dBA) | Resonant Frequency (Hz) | Operating Tempature (°C) | Housing | Weight (g) |
|---|---|---|---|---|---|---|---|---|---|---|
| CIT3012H27TP | 30 | 12 | 1.5 ~ 24 | 12 | 12 | 75 @ 1M | 2700 ± 500 | -20 ~ +105 | PBT | 5 |
Please contact us for the datasheet of this product.
