Self Drive Piezo Transducer (DC)
| Part No. | Diameter Φ (mm) | Height (mm) | Operating Voltage (VDC) | Rated Voltage (VDC) | Max Rated Current (mA) | Min Sound Output (dBA) | Resonant Frequency (Hz) | Operating Tempature (°C) | Housing | Weight (g) |
|---|---|---|---|---|---|---|---|---|---|---|
| CIT2211H35TP | 22.5 | 11 | 3 ~ 18 | 12 | 15 | 80 @ 30cm | 3500 ± 500 | -20 ~ +60 | PBT | 1.7 |
Please contact us for the datasheet of this product.
