External Drive Piezo Transducer (AC)

CPT4416
Part No.Diameter Φ (mm)Height (mm)Max. Input Voltage (V)Rated Voltage (VAC)Min Sound Output (dBA)Resonant Frequency (Hz)Capacitance @ 1KHz (pF)Operating Tempature (°C)HousingWeight (g)
CPT4416C10BP4416.530 Vp-p3 Vrms70 @ 10cm100080000 ± 30%-20 ~ +70ABS12
Please contact us for the datasheet of this product.
