Magnetic Transducer (AC)

CMT1005-X
Part No.Diameter Φ (mm)Height (mm)Operating Voltage (VAC)Rated Voltage (VAC)Max Rated Current (mA)Coil Resistance (Ω)Min Sound Output (dBA)Resonant Frequency (Hz)Operating Tempature (°C)TerminalHousingWeight (g)
CMT1005A2731NPX9.651 ~ 21.5805.5 ± 180 @ 10cm2731-20 ~ +60PinNoryl1
Please contact us for the datasheet of this product.
