Omni-Directional
| Part No. | Diameter Φ (mm) | Height (mm) | Sensitivity @ 1KHz (dB) | Standard Power Supply(Vs)(V) | S/N Ratio (dB) | Max Rated Current (mA) | Resistance Loading(RL)(Ω) | Frequency Range (Hz) | Terminal |
|---|---|---|---|---|---|---|---|---|---|
| CO Series | 4 ~ 10 | 1.2 ~ 6.7 | -36 ~ -50 | 1.5 ~ 4.5 | >60 | 0.5 | 1k ~ 2.2k | 50 ~ 16000 | Solder Pad, Bull Eye, Wire or Pin |
Please contact us for the datasheet of this product.
