Self Drive Piezo Transducer (DC)

CIT3012
Part No.Diameter Φ (mm)Height (mm)Operating Voltage (VDC)Rated Voltage (VDC)Max Rated Current (mA)Min Sound Output (dBA)Resonant Frequency (Hz)Operating Tempature (°C)HousingWeight (g)
CIT3012H27TP30121.5 ~ 24121275 @ 1M2700 ± 500-20 ~ +105PBT5
Please contact us for the datasheet of this product.
