SMD External Drive Piezo Transducer (AC)

CSPT1706
Part No.Length (mm)Height (mm)Max. Input Voltage (V)Rated Voltage (VAC)Min Sound Output (dBA)Resonant Frequency (Hz)Capacitance @ 1KHz (pF)Operating Tempature (°C)HousingWeight (g)
CSPT1706I40LΦ 17625 Vp-p12 Vp-p90 @ 10cm400015000 ± 30%-20 ~ +75PPS2
Please contact us for the datasheet of this product.
