SMD External Drive Piezo Transducer (AC)
| Part No. | Length (mm) | Height (mm) | Max. Input Voltage (V) | Rated Voltage (VAC) | Min Sound Output (dBA) | Resonant Frequency (Hz) | Capacitance @ 1KHz (pF) | Operating Tempature (°C) | Housing | Weight (g) |
|---|---|---|---|---|---|---|---|---|---|---|
| CSPT1705C40L | Φ 17 | 5.2 | 30 Vp-p | 3 Vrms | 80 @ 10cm | 4000 | 6500 ± 30% | -20 ~ +70 | LCP | 3 |
Please contact us for the datasheet of this product.
