SMD External Drive Piezo Transducer (AC)
| Part No. | Length (mm) | Height (mm) | Max. Input Voltage (V) | Rated Voltage (VAC) | Min Sound Output (dBA) | Resonant Frequency (Hz) | Capacitance @ 1KHz (pF) | Operating Tempature (°C) | Housing | Weight (g) |
|---|---|---|---|---|---|---|---|---|---|---|
| CSPT1602C40LS | 16 X 16 | 2.5 | 25 Vp-p | 3 Vp-p | 73 @ 10cm | 4000 | 14000 ± 30% | -20 ~ +70 | PPS | 1 |
Please contact us for the datasheet of this product.
