External Drive Piezo Transducer (AC)
| Part No. | Diameter Φ (mm) | Height (mm) | Max. Input Voltage (V) | Rated Voltage (VAC) | Min Sound Output (dBA) | Resonant Frequency (Hz) | Capacitance @ 1KHz (pF) | Operating Tempature (°C) | Housing | Weight (g) |
|---|---|---|---|---|---|---|---|---|---|---|
| CPT2206H25LP | 22 | 5.7 | 30 Vrms | 10 Vp-p | 80 @ 10cm | 2500 | 25000 ± 30% | -30 ~ +85 | LCP | 2 |
Please contact us for the datasheet of this product.
