External Drive Piezo Transducer (AC)
| Part No. | Diameter Φ (mm) | Height (mm) | Max. Input Voltage (V) | Rated Voltage (VAC) | Min Sound Output (dBA) | Resonant Frequency (Hz) | Capacitance @ 1KHz (pF) | Operating Tempature (°C) | Housing | Weight (g) |
|---|---|---|---|---|---|---|---|---|---|---|
| CPT1709G20NP | 17 | 8.6 | 25 Vrms | 9 Vp-p | 78 @ 10cm | 2000 | 25000 ± 30% | -20 ~ +60 | Noryl | 1 |
Please contact us for the datasheet of this product.
