External Drive Piezo Transducer (AC)
| Part No. | Diameter Φ (mm) | Height (mm) | Max. Input Voltage (V) | Rated Voltage (VAC) | Min Sound Output (dBA) | Resonant Frequency (Hz) | Capacitance @ 1KHz (pF) | Operating Tempature (°C) | Housing | Weight (g) |
|---|---|---|---|---|---|---|---|---|---|---|
| CPT1707C20BW | 16.8 | 7 | 30 Vrms | 3 Vp-p | 75 @ 10cm | 2000 | 23000 ± 30% | -20 ~ +70 | ABS | 1 |
Please contact us for the datasheet of this product.
