SMD Magnetic Transducer (AC)

CSMT1003-S
Part No.Length (mm)Height (mm)Operating Voltage (VAC)Rated Voltage (VAC)Max Rated Current (mA)Coil Resistance (Ω)Min Sound Output (dBA)Resonant Frequency (Hz)Operating Tempature (°C)HousingWeight (g)
CSMT1003E2700LS10 X 103.23 ~ 7510040 ± 585 @ 10cm2700-30 ~ +70LCP0.9
Please contact us for the datasheet of this product.
