Magnetic Transducer (AC)
| Part No. | Diameter Φ (mm) | Height (mm) | Operating Voltage (VAC) | Rated Voltage (VAC) | Max Rated Current (mA) | Coil Resistance (Ω) | Min Sound Output (dBA) | Resonant Frequency (Hz) | Operating Tempature (°C) | Terminal | Housing | Weight (g) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| CMT0704A2730NP | 6.7 | 9 | 1 ~ 4 | 1.5 | 80 | 8 ± 1 | 70 @ 10cm | 2730 | -20 ~ +80 | Pin | Noryl | 1 |
Please contact us for the datasheet of this product.
